2652030000 - 15-Pole Terminal Block with 90-Degree Outlet, 5.08mm Pitch (Pack of 48)
2652030000 - 15-Pole Terminal Block with 90-Degree Outlet, 5.08mm Pitch (Pack of 48)
SKU: SKU: 2652030000 Download PDF
- 2652030000 - 15-Pole Terminal Block with 90-Degree Outlet, 5.08mm Pitch (Pack of 48)
- 2652030000 - 15-Pole Terminal Block with 90-Degree Outlet, 5.08mm Pitch (Pack of 48)
Couldn't load pickup availability
Description:
Introducing the TPS 508/15/90 50SN GN BX terminal block, a versatile solution designed for compatibility with various conductor types This model features a practical clamping yoke connection method for securely attaching wires, making it suitable across multiple applications With a 90-degree conductor outlet and 15 poles arranged in a single pin series, this terminal block accommodates wire sizes ranging from AWG 30 to AWG 12.
It boasts a compact pitch of 508 mm and a rated voltage of 300 V, ensuring reliable performance Capable of operating at a maximum temperature of 105 °C, it also withstands a broad range of storage temperatures, offering flexibility and durability for your electrical needs.
Features and Benefits:
•Clamping yoke connection method for secure wiring.
•Easy to mount onto PCBs with THT solder connection.
•Compact design with 90° conductor outlet.
•Made from durable insulating material - PA.
•Compliant with RoHS and REACH regulations.
Specifications:
| IEC rated voltage | 320 V |
| IEC rated current | 20 A |
| UL rated voltage | 300 V |
| UL rated current | 15 A |
| Pitch in mm | 5.08 mm |
| Number of poles | 15 |
| Solder pin length | 5 mm |
| Tightening torque, min. | 0.5 Nm |
| Tightening torque, max. | 0.55 Nm |
| Protection degree | IP20 |
| Storage temperature, min. | -40 °C |
| Storage temperature, max. | 70 °C |
| Operating temperature, max. | 105 °C |
| Insulating material | PA |
| UL 94 flammability rating | V-0 |
