Description:
Introducing the TSS 500/19/135 33SN GN BX, a highly compliant terminal block perfect for your PCB projects This component connects via a reliable clamping yoke and is designed for thorough THT soldering, featuring a 135-degree conductor outlet angle With a compact 5 mm pitch, it hosts 19 poles aligned in a single row, each accommodating a solder pin measuring 33 mm in length The pins themselves are dimensioned at 0.
8 x 09 mm and hold an IP20 protection rating, ensuring dependable performance
This adaptable terminal block supports a variety of conductor sizes, ranging from 02 to 25 mm² or AWG 30 to AWG 12, making it suitable for both solid and flexible wiring Constructed from PA insulating material, the product is available in a soft pale green shade and meets the UL 94 V-0 flame rating standards Weighing in at 45.
6 grams, this terminal block combines functionality with safety, making it an excellent choice for your electronic applications.
Features and Benefits:
•Clamping yoke connection method.
•THT solder connection for PCB mounting.
•135° conductor outlet direction.
•Rated for IP20 protection.
•Insulating material made of PA.
•UL 94 flammability rating of V-0.
•Net weight is 45.6 grams.
Specifications:
| Rated Voltage (IEC) | 630 V |
| Rated Current (IEC) | 20 A |
| Solder Pin Length | 3.3 mm |
| Pitch | 5 mm |
| Conductor Outlet Direction | 135° |
| Number of Poles | 19 |
| Rated Impulse Voltage II/2 | 4 kV |
| Ambient Temperature Range | -40 °C to 105 °C |
| Clamping Range (min) | 0.2 mm² |
| Clamping Range (max) | 2.5 mm² |
