2651440000 - 5.08mm 13-Pole OMNIMATE Terminal for Right-Angle Connections (Pack of 64)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the OMNIMATE basic series clamping yoke, expertly engineered for right-angle conductor outlets with a 90° direction This robust connector features 13 poles and THT solder connections, all arranged with a 508 mm pitch Weighing in at just 1339 g, the component boasts PA insulation, ensuring durability and compliance with RoHS standards Versatile in application, it accommodates both solid and flexible wire connections within its specified clamping range.

With a maximum rated current of 15 A and an IP20 rating for protection, this terminal is the ideal solution for reliable connections in various setups.

Features and Benefits:

•Compact design with 90° conductor outlet for space-saving applications.

•High current rating of 15 A for efficient power handling.

•Supports multiple wire sizes for flexible installation options.

•RoHS compliant ensuring environmental safety.

Specifications:
