2650980000 - 5-Pole PCB Connector, 90° Outlet, 5mm Pitch, UL Rated (Pack of 200)
2650980000 - 5-Pole PCB Connector, 90° Outlet, 5mm Pitch, UL Rated (Pack of 200)
SKU: SKU: 2650980000 Download PDF
- 2650980000 - 5-Pole PCB Connector, 90° Outlet, 5mm Pitch, UL Rated (Pack of 200)
- 2650980000 - 5-Pole PCB Connector, 90° Outlet, 5mm Pitch, UL Rated (Pack of 200)
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
Introducing the TMS 500/05/90 30SN GN BX, an expertly crafted connection solution built for seamless PCB mounting via a clamping yoke mechanism This component showcases a 90-degree outlet orientation and features a compact pitch of 5 mm With five poles, it upholds UL standards and is rated for 15 A at 300 V, ensuring high performance and reliability Each box contains 200 units, and the product meets RoHS compliance guidelines, making it a smart choice for your electronic projects.
Features and Benefits:
•Compliance with RoHS regulations and certified for cURus.
•Clamping yoke connection simplifies installation.
•Suitable for a wide range of conductor sizes from 0.2 mm² to 2.5 mm².
•Compact design with a low stripping length requirement of 6 mm.
•Rated for high current and voltage applications.
Specifications:
| Approval Certificate Number | E60693 |
| Rated Current | 15 A |
| Rated Voltage | 300 V |
| Wire Connection Method | Clamping yoke connection |
| Number of Poles | 5 |
| Pitch | 5 mm |
| Protection Degree | IP20 |
| Solder Pin Dimensions | 0.7 x 0.9 mm |
| Insulating Material | PA |
| UL 94 Flammability Rating | V-0 |
| Storage Temperature (min) | -40 °C |
| Storage Temperature (max) | 70 °C |
| Operating Temperature (max) | 105 °C |
| Net Weight | 5.15 g |
