2652050000 - 5.08mm 17-Pole Connector, 90° Outlet, UL & RoHS Compliant (Pack of 40)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the TPS 508/17/90 50SN GN BX connector, a robust solution designed to meet UL and RoHS compliance standards This specialized connector is ideal for applications requiring a reliable clamping yoke connection and is compatible with THT solder installation With a pitch measurement of 508 mm and ensuring a 90° outlet direction for conductors, this connector boasts 17 poles It provides strong performance with a minimum tightening torque of 0.

5 Nm and a maximum of 055 Nm Crafted from high-quality PA insulating material, it guarantees excellent insulation and aligns with regulations concerning hazardous substances Suitable for operating temperatures up to 105 °C and storage temperatures reaching 70 °C, this connector is both versatile and dependable for your electrical needs.

Features and Benefits:

•Compliant with RoHS and UL standards.

•Designed for use with OMNIMATE basic products.

•Includes a robust clamping yoke connection method.

•Flexible wiring options ranging from 0.05 mm² to 4 mm².

•Compact pin series quantity with a single solder pin per pole.

•Heat-resistant with a UL 94 flammability rating of V-0.

Specifications:
