2651470000 - 5.08mm 16-Pole Terminal Block, RoHS, 105°C Rated (Pack of 48)

Description:

Discover the efficiency of the OMNIMATE basic series with this reliable wire connection terminal block Featuring a clamping yoke connection method, it boasts a 508 mm pitch and supports 16 poles, each with a dedicated solder pin This terminal block is ideal for solid or flexible conductors, accommodating sizes from 02 mm² to 25 mm², while ensuring secure connections with specific torque ratings Designed for through-hole soldering on PCBs, it operates effectively in temperatures up to 105 °C.

With a pale green finish and compliance with RoHS standards, this terminal block is built for performance and adherence to environmental regulations.

Features and Benefits:

•Compliant with RoHS and UL standards.

•Connects conductors with a minimum of 0.2 mm² and maximum of 2.5 mm².

•Can handle a tightening torque between 0.5 Nm and 0.55 Nm.

•Designed for THT solder connection with a 90° conductor outlet direction.

•Insulating material rated for UL 94 flammability V-0.

•Suitable for use with OMNIMATE basic products.
