2650490000 - 3.81mm 8-Pole Yoke Connection Terminal Block, 90° Angle (Pack of 256)
2650490000 - 3.81mm 8-Pole Yoke Connection Terminal Block, 90° Angle (Pack of 256)
SKU: SKU: 2650490000 Download PDF
- 2650490000 - 3.81mm 8-Pole Yoke Connection Terminal Block, 90° Angle (Pack of 256)
- 2650490000 - 3.81mm 8-Pole Yoke Connection Terminal Block, 90° Angle (Pack of 256)
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
Introducing the TCS 381/08/90 35SN GN BX—an efficient clamping yoke connection terminal block designed for through-hole soldering With a compact pitch of 381 mm, this terminal block contains 8 poles arranged in a single row, facilitating a straightforward connection process The solder pins are 35 mm long and sized at 05 x 09 mm, allowing for reliable electrical connections at a 90-degree output angle.
Perfect for various applications, this component combines functionality with precision engineering.
Features and Benefits:
•Net weight of 3.68 g.
•Protection degree IP20.
•Insulating material is PA.
•V-0 flammability rating as per UL 94.
•Compatible with OMNIMATE basic products.
Specifications:
| IEC Rated Voltage | 320 V |
| IEC Rated Current | 10 A |
| Clamping range (min) | 0.2 mm² |
| Clamping range (max) | 1.5 mm² |
| Wire connection cross section AWG, min. | AWG 26 |
| Wire connection cross section AWG, max. | AWG 16 |
| Operating temperature, max. | 105 °C |
| Storage temperature, min. | -40 °C |
| Storage temperature, max. | 70 °C |
| Number of solder pins per pole | 1 |
| Tightening torque, min. | 0.2 Nm |
| Tightening torque, max. | 0.23 Nm |
