2650550000 - 14-Pole Clamping Yoke PCB Connector for THT Solder (Pack of 128)

Description:

Introducing the TCS 381/14/90 35SN GN BX, a precision-engineered component that adheres to multiple industry standards It boasts a clamping yoke connection for reliable wire integration and is tailored for through-hole soldering, with the conductor exiting at a 90° angle Comprising 14 poles, this unit is designed for PCB mounting Weighing just 644 grams, it is packaged in a convenient box This versatile product accommodates conductor sizes from 0.

2 to 15 mm², or AWG 26 to AWG 16, making it a smart choice for various applications.

Features and Benefits:

•RoHS compliant.

•Solder pin dimensions of 0.5 x 0.9mm.

•Tightening torque range from 0.2 to 0.23 Nm.

•Protection degree of IP20.

•Insulating material made of PA.

•UL 94 flammability rating of V-0.

•Long-term storage of the product is suitable under specified temperature and humidity conditions.

•Compatible with OMNIMATE basic products.
