2650430000 - 3.81mm 2-Pole PCB Terminal Block, 90° Outlet, RoHS Compliant (Pack of 1000)

Description:

Introducing the TCS 381/02/90 35SN GN BX terminal block, designed for efficient PCB mounting with through-hole solder connections This model is distinguished by its 90-degree conductor outlet direction and features a pitch of 381 mm (015 inches) Capable of supporting 2 poles with a single pin series, it operates at a maximum voltage of 320 V and current of 10 A in compliance with IEC standards, as well as 150 V and 10 A per UL standards.

This terminal block adheres to RoHS guidelines and is suitable for both storage and usage in temperatures ranging from -40 °C to 105 °C Made from PA insulating material, it comes in an attractive pale green shade that corresponds with RAL 6021.

Features and Benefits:

•Clamping yoke connection allows for robust electrical connections.

•Suitable for various wire cross-sections from 0.2 mm² to 1.5 mm².

•Compliant with RoHS and REACH regulations.

•Designed with IP20 protection degree for environmental safety.

•Compatible only with OMNIMATE basic product range.

•Used for electrical connections on printed circuit boards.

Specifications:
