2712470500 - 5m Heavy Duty 8-Pole Connector Assembly, RoHS Compliant
2712470500 - 5m Heavy Duty 8-Pole Connector Assembly, RoHS Compliant
SKU: SKU: 2712470500 Download PDF
- 2712470500 - 5m Heavy Duty 8-Pole Connector Assembly, RoHS Compliant
- 2712470500 - 5m Heavy Duty 8-Pole Connector Assembly, RoHS Compliant
Couldn't load pickup availability
Description:
Discover robust connector assemblies designed for heavy-duty applications This product features pin and socket connectors, tailored for compatibility with Helukabel JZ-500 10G25 or similar materials With a total of 8 poles and no shielding, it meets RoHS compliance standards Weighing in at 1,72652 grams, it operates efficiently within a temperature range of -40 °C to 80 °C, making it suitable for a variety of environments.
Features and Benefits:
•Compliant with RoHS exemption 6c.
•Protection degree IP65.
•Suitable for various industrial applications.
Specifications:
| Nominal voltage | 500 V |
| Number of poles | 8 |
| Pin arrangement | 1:1, numbered cores |
| Bending radius, min., moving | 7.5 x cable diameter |
| Bending radius, min., stationary | 4 x cable diameter |
| Cable length | 5 m |
| Core cross-section | 2.5 mm² |
| Halogen | Yes |
| Insulation | PVC |
| Line type | Helukabel JZ-500 10G2.5 or similar |
| Number of wires | 10 |
| Outside diameter | 14.8 mm |
| Sheath material | PVC |
| Temperature range, moving, max. | 80 °C |
| Temperature range, moving, min. | -15 °C |
| Temperature range, stationary, max. | 80 °C |
| Temperature range, stationary, min. | -40 °C |
