Description:
Introducing a robust connector assembly that excels in demanding environments This heavy-duty unit features a socket connector type, specifically the Helukabel JZ-500-C in a sleek black finish, ensuring reliability and high performance With 6 poles, this assembly is shielded and adheres to RoHS regulations, including its exemptions
Engineered to withstand temperatures ranging from -40 °C to 80 °C, it is ideal for various environmental conditions.
The connector boasts a straight cable entry and is crafted from durable die-cast zinc housing, providing added strength Notably, it features an IP65 protection rating, highlighting its resilience against dust and water ingress.
Features and Benefits:
•ROHS compliant with exemptions.
•Rated for nominal voltage of 500 V.
•IP65 protection degree for enhanced durability.
•Connector has a 1:1 pin arrangement with numbered cores.
•Suitable for both moving and stationary applications.
Specifications:
| Connector | Female type with straight cable entry |
| Housing main material | Die-cast zinc |
| Cable length | 5 m |
| Core cross-section | 2.5 mm² |
| Number of wires | 7 |
| Outside diameter | 12.1 mm |
| Bending radius, min., moving | 10 x cable diameter |
| Bending radius, min., stationary | 5 x cable diameter |
| Temperature range, moving, max. | 80 °C |
| Temperature range, moving, min. | -10 °C |
| Temperature range, stationary, max. | 80 °C |
| Temperature range, stationary, min. | -40 °C |
| Sheath material | PVC |
| Insulation | PVC |
| Halogen | Yes |
| Protection degree | IP65 |
| Pin arrangement | 1:1, numbered cores |
