PCE-P50 - High-Accuracy Differential Pressure Gauge with RS232 Interface

PCE-P50 - High-Accuracy Differential Pressure Gauge with RS232 Interface

SKU: PCE-P50   Download PDF

Select a Variant:
  • PCE-P50 - High-Accuracy Differential Pressure Gauge with RS232 Interface
Qty:
Now $323.00   Web pricing policy
BEFORE   $0.00 Now $323.00 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information Resources Reviews
Product Information

Description:

Introducing the PCE-P50 Pressure Gauge, a professional-grade instrument equipped with an RS232 interface and accompanying software Engineered to accurately measure overpressure, underpressure, and differential pressure in air and gases, this gauge excels in performance and precision Ideal for industrial settings, laboratory experiments, and service applications, it reliably assesses non-corrosive media.

The PCE-P50 boasts overload protection that withstands two times its measuring range and offers nine selectable units for effortless measurement conversions, enhancing its versatility for various tasks Experience seamless data transfer to your PC or laptop for efficient monitoring and analysis.

Features and Benefits:

    •9 selectable units for versatile applications.

    •Digital display for clear readings of over, under, or differential pressure.

    •Min/Max memory function for tracking extremes.

    •Data hold function to freeze displayed values.

    •Backlit LCD display for visibility in various lighting conditions.

    •Impact-resistant ABS housing for durability.

    •Auto-power-off function to conserve battery life.

    •Pneumatic applications on compressors and pumping systems.

    •Chemical processes for control and measurements on pressure tanks.

    •Manufacturing processes, particularly in the plastics industry.

    •Checking valve controls and monitoring air loss.

    •Research and development activities.

    •General optimization and testing during process management.

    •Authorization requirements in heating and air conditioning systems.

Specifications:

 Max. Pressure 150 psi
 Range (mbar) 0...±6900
 Resolution (mbar) 4
 Range (inHg) 0...±2750
 Resolution (inHg) 2
 Range (mmHg) 0...±200
 Resolution (mmHg) 0.1
 Range (kPa) 0...±5200
 Resolution (kPa) 3
 Range (cmH2O) 0...±690
 Resolution (cmH2O) 0.4
 Range (Kg/cm²) 0...±7000
 Resolution (Kg/cm²) 4
 Data format Baud rate: 2400 baud, 1 stop bit, 8 data bits
 Accuracy ±0.3 % (full range, @ +25°C / +77°F)
 Repeatability ±0.2 % (max. ±0.5 % of full scale)
 Duration 0.3 ms
 Operating temperature max +50 °C / +122 °F
 Power supply 9 V DC / power converter (optional), 1 x 9 V - block battery PP3
 Dimensions 182 x 72 x 30 mm / 7.1 x 2.8 x 1.1"
