PCE-P30 - Professional Differential Pressure Meter with RS232 Interface

PCE-P30 - Professional Differential Pressure Meter with RS232 Interface

SKU: PCE-P30 Download PDF

Variant:
  • PCE-P30 - Professional Differential Pressure Meter with RS232 Interface
Now $284.00
BEFORE   $0.00 Now $284.00
Sold out
Web pricing policyShipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000.* Only on standard purchases of cables and wires.
View full details
Product Information Resources Reviews
Product Information

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the PCE-P30 Pressure Meter, a top-tier instrument designed for precise measurement of overpressure, underpressure, and differential pressure in air and gas applications This professional-grade meter stands out with its exceptional accuracy and reliable performance With a user-friendly RS232 interface, you can effortlessly transfer pressure data directly to your PC or laptop Its robust design makes it ideal for industrial environments, service sectors, and laboratory use, specifically tailored for non-corrosive media.

Safety is prioritized with overload protection that accommodates pressures twice the measuring range The gauge displays readings in nine different units, enhancing versatility and eliminating the hassle of manual conversions For enhanced functionality, optional software and an RS-232 interface cable are available for seamless data transfer to various Windows systems The device not only presents data visually but also allows you to save measurements for future reference and analysis.

Features and Benefits:

    •9 selectable units.

    •Digital display of over, under (vacuum) or differential pressure.

    •Min / Max memory.

    •Data hold function.

    •Backlit LCD display.

    •Impact-resistant ABS housing.

    •Auto-power-off function.

    •Pneumatic area, on compressors and pumping systems.

    •Chemical area for process control and measurements on pressure tanks.

    •Manufacturing area for compressed air processes in plastics industry.

    •Checking valve controls in compressed air systems.

    •Research and development area.

    •Optimization and testing in various processes.

    •Authorization for heating and air conditioning systems.

Specifications:

 Max Pressure 60 psi
 Pressure Range 0...±30 PSI
 Resolution 0.02 mbar
 Range 0 0...±2000 inH2O, Resolution 2
 Range 1 0...±830 inHg, Resolution 0.5
 Range 2 0...±61 mmHg, Resolution 0.01
 Range 3 0...±1500 kPa, Resolution 1
 Range 4 0...±200 cmH2O, Resolution 0.2
 Range 5 0...±2100 Kg/cm², Resolution 2
 Range 6 0...±2.1, Resolution 0.002
 Data format Baud rate: 2400 baud, 1 stop bit, 8 data bits
 Accuracy ±0.3 % (full range, @ +25°C / +77°F)
 Repeatability ±0.2 % (max. ±0.5 % of full scale)
 Duration 0.3 ms
 Operating temperature max +50 °C / +122 °F
 Battery 1 x 9 V - block battery PP3
 Dimensions 182 x 72 x 30 mm / 7.1 x 2.8 x 1.1"
