PCE-PDA 01L - Advanced Manometer with Data Logging & Pitot Tube Functionality

PCE-PDA 01L - Advanced Manometer with Data Logging & Pitot Tube Functionality

SKU: PCE-PDA 01L Download PDF

Variant:
  • PCE-PDA 01L - Advanced Manometer with Data Logging & Pitot Tube Functionality
Now $1,041.00
BEFORE   $0.00 Now $1,041.00
Sold out
Web pricing policyShipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000.* Only on standard purchases of cables and wires.
View full details
Product Information Resources Reviews
Product Information

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

The PCE-PDA Series Manometer is a versatile tool tailored for precise measurement of both relative and differential pressure in gases It comes equipped with an adaptable Pitot tube and boasts a MAX MIN function alongside data logging features This manometer operates within a measurement range of ± 200 Pa, ± 2 kPa, and 20 kPa, supporting over 16 different measurement units It also tracks temperature, flow velocity, and volume flow, providing users with comprehensive monitoring capabilities.

The two-part graphic display allows easy access to maximum and minimum differential pressure readings, while the high-precision mode ensures enhanced resolution Additional specialized modes facilitate efficient leak test procedures With optional Pitot tubes, this device can also calculate flow velocity and volume flow in piping systems, making it an invaluable asset for various applications.

Features and Benefits:

    •Graphic display with lighting.

    •Min and Max value memory.

    •Datalogger and leak test functionality.

    •Quick coupling connection for ease of use.

    •Temperature, flow, and leakage measurement capabilities.

    •High precision measuring mode.

    •Simple operation through voice control.

    •Switchable measurement units.

Specifications:

 Measuring range temperature 0 ... 50°C / 32 ... 122°F
 Resolution (temperature) 0.1°C / 0.18°F
 Accuracy (temperature) ± 1°C / 1.8°F
 Measuring range pressure ± 200 Pa
 Resolution (pressure) 0.01 / 0.1 Pa
 Accuracy (pressure) ± 1% of final value
 Nominal pressure 200 Pa
 Overpressure 1 kPa
 Burst pressure 20 kPa
 Media air
 Measuring rate 10 Hz
 Measurement units Pa, hPa, kPa, MPa, mbar, bar, ATM, kg / cm², mmH2O, cmH2O, inH2O, mmHg, inHg, Torr, PSI, PSF
 Pressure connections 5 mm nipple for quick connectors
 Max, Min and Hold function Yes
 Data logger 1024 memory slots, recording time from 1 s ... 255 h, recording interval from 1 s ... 24h
 Medium For air and non-explosive gasses
 Zero correction Yes, with a zero key
 Averaging Yes, between 0.1 ... 9.9 s
 Display Graphic LCD with backlight
 Protection IP41
 Power supply 2 x 1.5V AA battery / 1.2V NiMh battery, 5V / 500-mA USB power adapter
 Current consumption 50-mA (with backlight), 10-mA (without backlight)
 Operating temperature 0 ... 50°C / 32 ... 122°F
 Storage temperature 10 ... 55°C / 50 ... 131°F
 Dimensions 145 x 85 x 35 mm / 5.7 x 3.3 x 1.4 in
