PCE-ITE 50 - Versatile 3.5" Insulation Tester for Electrical Safety Measurements

Description:

Introducing the PCE-ITE 50, a heavy-duty installation tester equipped with a 35-inch TFT color LCD display for clear visibility This versatile tool allows you to measure insulation resistance, earthing resistance, loop impedance, and voltage, alongside low resistance measurements and RCD testing, all in one device One standout feature is its ability to document measurements with accompanying photos, ensuring thorough reporting.

The intuitive dual display and user-friendly symbols streamline the measuring process, making it quick and efficient With its capacity for low-resistance measurement, the PCE-ITE 50 effectively evaluates grounding conductors, potential equalization rails, and protective conductors, featuring a measurement range of 0 - 2000 Ω and a resolution from 0001 to 1 Ω The insulation resistance function applies test voltages of 125V, 250V, 500V, or 1000V, identifying fault currents that can lead to material degradation or overheating, which could pose fire risks if undetected.

Operating independently from mains supply, this tester is critical for verifying that all systems in a power supply network remain at a common ground potential to mitigate short-circuit and overvoltage hazards, with an earthing resistance measurement range of 0 - 2000 Ω and a resolution of 001 - 1 Ω Ensure your electrical installations are safe and compliant with the reliable PCE-ITE 50 installation tester.

Features and Benefits:

•3.5 inch TFT color LCD display.

•Loop resistance L-N, L-PE and N-PE.

•Adjustable FI test current.

•SD card and Bluetooth.

•Dual display.

•Good / bad FI test.

•Low Ohm measurement.

•Up to 1000V terminal voltage.
