PCE-DPD-F1 - 1/8 DIN Digital Force Meter with 6-Digit LED Display

Description:

The PCE-DPD-F1 Panel Meter is specifically engineered for displaying force measurements from strain gauges with mV and V inputs It comes equipped with a modular output card system and features a clear 6-digit LED display This versatile meter can operate on either a 230V or 24V power supply Internally, it shows the force and weight captured by the connected strain gauge sensors and load cells The meter adeptly handles the output signal of the measuring cell, allowing for accurate weight readings in mV/V concerning the predetermined sensitivity.

Users have the flexibility to scale and modify the displayed units effortlessly It also provides adjustable voltage supplies for the linked measuring cells, choosing between 5V and 10V, which means it can accommodate up to 8 or 4 force/load cells, respectively Customization options via different output cards cater to various application requirements Built with 1/8 DIN panel mounting dimensions, this digital mV/V display is perfect for a wide range of uses.

Features and Benefits:

•Digital display specifically for strain gauges.

•mV/V input capabilities.

•Three adjustable measuring speeds.

•Availability of modular output cards for application-specific needs.

•Compact 1/8 DIN panel mounting size.

•High visibility LED display.

Specifications:
