FM202-UN-SY-10-600 - 600 N Electronic Closing Force Measurement Tool

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the Closing Force Measuring Device, an advanced electronic tool crafted for the precise measurement of power-operated systems such as windows, sliding roofs, doors, and retractable steps in both automotive and rail applications This sturdy instrument supports measurements of up to 600 N, featuring a spring stiffness of 10 N/mm for enhanced accuracy Its sophisticated software simplifies the measurement and documentation processes, allowing for efficient testing and production workflows, quick data evaluations, and seamless integration into automated testing setups.

Features and Benefits:

•Applicable to standards like 2000/4/EC or customizable as per user requirements.

•Precision in measurement is ensured by a frictionless guide and platform load cell.

•Robust construction with high-strength aluminum and stainless steel for longevity.

•User-friendly operation with a single control button or remote via MS DLL or LabView.

•Comprehensive PinchPilot PC software enhances measurement and documentation capabilities.

•Wide measuring range with a maximum force capacity of 600 N at a spring stiffness of 10 N/mm.

•Includes provisions for excess force measurement.

•Complete delivery with all components housed in a high-quality carrying case.

•Used for measuring closing force in automotive applications including windows and sliding roofs, as well as doors and sliding steps in rail vehicles..

Specifications:
