2793350000 - 0.3m IP67 LED Module Cable for 24V Lighting Solutions
2793350000 - 0.3m IP67 LED Module Cable for 24V Lighting Solutions
SKU: SKU: 2793350000 Download PDF
- 2793350000 - 0.3m IP67 LED Module Cable for 24V Lighting Solutions
- 2793350000 - 0.3m IP67 LED Module Cable for 24V Lighting Solutions
Couldn't load pickup availability
Description:
Illuminate your space with this versatile LED module cable, measuring 03 meters in length Engineered for optimal performance, it effectively connects LED modules, supporting an operational voltage of 24 V DC and accommodating a maximum current of 1188 A, resulting in a power output of 285 W Crafted with a robust anodised aluminium casing, this cable guarantees both durability and structural strength.
Plus, with its IP67 rating, it offers impressive protection against environmental factors, making it a reliable choice for all lighting applications.
Features and Benefits:
•Dimmable functionality.
•Impact resistance rated at IK05.
•Operating life expectancy of 60,000 hours.
•Screw mounting design.
•Pre-assembled cable for easy installation.
•Light color temperature of 4000K, neutral white.
•Illumination level reaching 1,069 lux.
•Luminosity capacity of 650 candela.
Specifications:
| Operating temperature: | -20 - 60°C |
| Cable Material: | PUR |
| Sheathing colour: | black |
| Housing main material: | hard anodised aluminium |
| Cable length: | 0.3 m |
| Core cross-section: | 0.34 mm² |
| Number of poles: | 2 |
| Connection thread: | M12 |
| Tightening torque: | 0.8 Nm |
| Rated voltage: | 24 V DC |
| Rated current: | 1.188 A |
| Power: | 28.5 W |
| Number of LEDs: | 54 |
| Light current: | 3,624 lm |
| Emitting angle: | 40° |
| Protection degree: | IP67 |
| Efficiency class: | F |
