Description:
Introducing a versatile pre-assembled cable measuring 03 meters in length, crafted from high-quality PUR material This cable is engineered for a wide range of applications and operates efficiently in temperatures from -20 to 60 degrees Celsius It is RoHS compliant, underscoring its eco-friendly design With an impressive IP67 rating, it is both dustproof and waterproof, making it ideal for challenging environments.
Capable of handling a rated voltage of 24V DC and a maximum current of 031A, it delivers a power output of 75W The LED module emits a bright light at 6500K, producing a luminosity of 3,470 cd, perfect for a variety of lighting needs.
Features and Benefits:
•RoHS compliant with exemptions.
•LED module is not attachable.
•Dimmable functionality.
•Operating life of 60,000 hours.
•Suitable for NEC Class 2 applications.
Specifications:
| Depth | 40 mm |
| Height | 8 mm |
| Width | 240 mm |
| Cable Material | PUR |
| Sheathing color | black |
| Housing main material | hard anodised aluminium |
| Cable length | 0.3 m |
| Core cross-section | 0.34 mm² |
| Number of poles | 2 |
| Connection thread | M12 |
| Tightening torque | 0.8 Nm |
| Rated voltage | 24 V DC |
| Rated current | 0.31 A |
| Power | 7.5 W |
| Light colour (CCT) | 6500K |
| Luminosity | 3,470 cd |
| Light current | 886 lm |
| Emitting angle | 40 ° |
| Illumination level | 291 lux |
| Type of mounting | Screw mounting |
| Impact resistance | IK05 |
| Protection degree | IP67 |
