2535770000 - 0.3m PUR Cable with M12 A-coded Connector, 24V DC
2535770000 - 0.3m PUR Cable with M12 A-coded Connector, 24V DC
SKU: SKU: 2535770000 Download PDF
- 2535770000 - 0.3m PUR Cable with M12 A-coded Connector, 24V DC
- 2535770000 - 0.3m PUR Cable with M12 A-coded Connector, 24V DC
Couldn't load pickup availability
Description:
Introducing a pre-assembled cable engineered for a wide range of environmental conditions, functioning seamlessly in temperatures from -20°C to 60°C Crafted from durable PUR material, it boasts a robust black sheath and houses its components within a hard anodised aluminium casing Featuring a two-pole design, the cable includes an A-coded M12 connection thread and is rated for a voltage of 24 V DC, handling a maximum current of 0.
162 A The assembly also integrates 7 LED modules that emit a striking light color temperature of 6500K, delivering impressive luminosity of 3,470 cd and a light current of 443 lm With an impressive operational lifespan of 60,000 hours, this cable is built to last.
Features and Benefits:
•Dimmable function.
•Screw mounting type.
•Protection degree of IP67.
•Impact resistance rating of IK05.
•Efficiency class G according to EU Directive No. 874/2012.
•Light emitting angle of 40 degrees.
Specifications:
| Depth | 40 mm |
| Height | 8 mm |
| Width | 145 mm |
| Cable Length | 0.3 m |
| Core Cross-section | 0.34 mm² |
| Rated Voltage | 24 V DC |
| Rated Current | 0.162 A |
| Power | 3.9 W |
| Number of LEDs | 7 |
| Light Colour (CCT) | 6500K |
| Operating Life | 60,000 h |
| Luminosity | 3,470 cd |
| Light Current | 443 lm |
| Illumination Level | 145 lux |
| Drill Hole Spacing | 130 mm |
| Tightening Torque | 0.8 Nm |
| Connection Data | Pin 4 (Strand: black) control white LED, Pin 3 (Strand: blue) |
| Shape of LED Module | Rectangular |
