2527920000 - 1.5m 24V DC Compliant Cable for LED Modules
2527920000 - 1.5m 24V DC Compliant Cable for LED Modules
SKU: SKU: 2527920000 Download PDF
- 2527920000 - 1.5m 24V DC Compliant Cable for LED Modules
- 2527920000 - 1.5m 24V DC Compliant Cable for LED Modules
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
Introducing this versatile compliant cable, specially crafted for devices that utilize a 24V DC power supply It functions efficiently in a temperature range of -20 to 60 degrees Celsius With a core cross-section measuring 034 mm², this pre-assembled cable comes with an open-ended design, making it easy to integrate with LED modules It supports a rated current of 031 A and offers a power output of 7.
5 W, providing reliable performance for your electrical needs.
Features and Benefits:
•Operating temperature range between -20°C and 60°C.
•Compliant with RoHS without exemptions.
•Dimmable functionality.
•Screw mounting type for installation.
•IK05 impact resistance rating.
•IP67 protection degree.
Specifications:
| Cable Material | PUR |
| Cable length | 1.5 m |
| Rated voltage | 24 V DC |
| Number of poles | 2 |
| Shape of the LED module | Rectangular |
| Number of LEDs | 14 |
| Light colour (CCT) | 6500K |
| Emitting angle | 40° |
| Connection data | Pin 4 (Strand: black) control white LED, Pin 3 (Strand: blue) |
| Connection thread | without |
| Version | Cable end open |
| Housing main material | hard anodised aluminium |
| Material of LED cover | ESG |
| Material of end caps | PBT |
