7760054300 - RoHS Compliant Device, 89x90mm, 0.1-10A AC/DC Range

Description:

Introducing the EPAK-CM-CO-H device, specifically crafted for general applications and fully compliant with RoHS standards This versatile unit measures 100 mm in length, 90 mm in height, 175 mm in width, and has a depth of 89 mm, with a compact diameter of 2 mm Weighing just 80 grams, it’s easy to handle and install The device operates efficiently within a temperature range of -20 °C to 60 °C, while it can be stored in temperatures from -40 °C to 85 °C.

Its robust design allows for a humidity tolerance level between 5 to 95% relative humidity, making it suitable for various environments Featuring a current input range of 01 to 5A AC/DC and a measurement capacity of up to 10A AC, this device is equipped with built-in surge current protection, ensuring reliable performance Embrace safety and compliance with the EPAK-CM-CO-H, designed to meet rigorous environmental standards.

Features and Benefits:

•SIL compliant with IEC 61508.

•Alarm output for measurement range exceedance.

•DIP switch and potentiometer configuration.

•IP20 protection degree.

•Galvanic isolation between input, output, and supply.

Specifications:
