7760054181 - RoHS Compliant Device, -20°C to 60°C Operating Range

Description:

Introducing the EPAK-CI-CO device, engineered to perform exceptionally across a wide range of specifications This product complies with RoHS standards, demonstrating its commitment to environmental safety It operates efficiently in temperatures from -20 °C to 60 °C and can be stored in conditions ranging from -40 °C to 85 °C, making it versatile for various environments Equipped with multiple inputs and outputs, it supports input currents of 0 to 20 mA, with the same scaling available for outputs.

With an impressive accuracy of 015%, it operates with a nominal power consumption of just 17 VA, while maxing out at 12 W Featuring an IP20 protection rating, it ensures reliable performance Connections are made via screw terminals, with specific torque requirements for secure fastening.

Features and Benefits:

•Complies with IEC 61508 for SIL requirements.

•Galvanic isolation between input, output, and supply.

•Rapid step response time of less than or equal to 100 ms.

•Max. switching voltage for both AC and DC is 0 V.

•Temperature coefficient of less than or equal to 150 ppm/K.

•Rated voltage capacity of 300 V.

Specifications:
