2984630000 - 16mm² RoHS Feed-Through Terminal with 180° Outlet (Pack of 50)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the WGK series feed-through terminal, designed for versatility with a rated cross-section of 16 mm², crafted from high-quality Wemid (PA) material Compliant with RoHS regulations and part of the OMNIMATE Power collection, this terminal supports various wire connection techniques It features a reliable screw connection that allows conductors to exit at a 180° angle, accommodating multiple connection types.

For installation, a compatible screwdriver blade (type 10 x 55 TX 20) is required The adjustable tightening torque ranges from 2 Nm to 23 Nm Additionally, this terminal boasts touch-safe protection in accordance with DIN VDE 0470, with an IP20 rating for enhanced safety Perfect for your electrical projects, this terminal combines quality and functionality.

Features and Benefits:

•Conductors suitable for a wide range of clamping ranges from 0.5 mm² to 25 mm².

•Wire connection cross-section options include AWG 20 to AWG 4.

•Screw connection method for reliable performance.

•Touch-safe protection according to DIN VDE 0470.

•Application standards for clearance and creepage distances.

•Robust operating temperature range from -50 °C to 120 °C.

Specifications:
