2440640000 - OMNIMATE 16 mm² Feed-Through Terminal for UL Standards (Pack of 50)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the OMNIMATE Power series feed-through terminal, engineered for direct mounting applications This terminal supports a rated cross-section of 16 mm² and adheres to RoHS standards, boasting a UL File Number of E60693 It operates effectively at an IEC voltage of 500 V and handles a current rating of 76 A, with compatibility for wire cross-sections ranging from 05 mm² to 25 mm² Additionally, this product meets UL certification requirements, rated for up to 600 V and a maximum current of 85 A, ensuring reliable performance for your electrical needs.

Features and Benefits:

•Dielectric material made of Wemid (PA).

•Touch-safe protection according to DIN VDE 0470 (IP 20).

•Easy installation with cable lug options.

•Compatible with various conductor sizes and types.

Specifications:
