1937140000 - 95 mm² Grey Feed-Through Terminal with 180° Outlet (Pack of 10)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the WGK 95F VP/Z GY BX feed-through terminal, engineered for straightforward mounting and rated for a cross-section of 95 mm² This terminal features a grey screw connection made from durable Wemid (PA) material Certified under RoHS regulations and with UL File Number E60693, it guarantees compliance and safety Capable of accommodating cable lugs with ring or spade connections, its conductor outlet direction is set at a convenient 180°, and it is optimized for a single pole connection.

For added convenience, customer fitting is allowed, ensuring a secure setup with a tightening torque requirement between 15 Nm and 20 Nm Rated at IP 20 for touch safety, this versatile terminal performs well within a broad temperature range, making it suitable for diverse applications.

Features and Benefits:

•RoHS compliant.

•Direct mounting capability.

•IP 20 rated for touch safety.

•Allows customer fitting.

Specifications:
