2439490000 - 10mm² Screw Terminal, Direct Mount, 1 Pole, RoHS Compliant (Pack of 50)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the WGK 10/Z P GN/YE BX feed-through terminal, engineered for direct mounting applications This robust terminal boasts a rated cross-section of 10 mm² and is constructed from high-quality Wemid (PA) material It adheres to IEC standards with a compatibility of 500 V and 57 A, while also meeting UL standards at 300 V and 65 A Equipped with a screw connection method, it features a single pole with a conductor outlet angle of 180°.

Additionally, this terminal complies with RoHS regulations without exceptions and contains no SVHC substances exceeding 01 wt%.

Features and Benefits:

•Screw connection method.

•Compatible with various wire sizes from 0.5 mm² to 16 mm².

•Operates under high temperature ranges.

•Touch-safe protection according to DIN VDE 0470 (IP 20).

Specifications:
