2984600000 - OMNIMATE 95mm² Feed-Through Terminal, Box of 10 (Pack of 10)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing a robust feed-through terminal from the OMNIMATE Power series, designed for reliable electrical connections This terminal features a rated cross-section of 95 mm² and is constructed from durable Wemid (PA) material Each box contains 10 terminals, ready for direct mounting applications The IEC rating stands at 1000 V with a current capacity of 232 A, while the UL rating is 600 V with a 255 A capacity.

It accommodates a range of wire gauges from AWG 4 to kcmil 250, making it versatile for various projects Additionally, it adheres to RoHS standards and is free from any SVHC substances above 01 wt%.

Features and Benefits:

•Wire connection method: Screw connection.

•Conductor outlet direction: 180°.

•Number of poles: 1.

•Fitted by customer: Yes.

•Screwdriver blade type: TX 45.

•Minimum and maximum tightening torque: 15 Nm to 20 Nm.

•Touch-safe protection according to DIN VDE 0470: IP 20.

•Insulation material: Wemid (PA).

•Contact material: Cu-alloy with tinned surface.

•Flammability rating: UL 94 V-0.

Specifications:
