2984640000 - OMNIMATE Power Feed-Through Terminal, 16 mm², 500 V, 76 A (Pack of 50)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Discover the reliability of this OMNIMATE Power series feed-through terminal, expertly crafted to support a rated cross-section of 16 mm² It adheres to IEC regulations with a voltage capacity of 500 V and a current rating of 76 A, suitable for cable sizes ranging from 05 to 25 mm² Additionally, it complies with UL standards, allowing for a maximum voltage of 600 V and accommodating a current of 85 A for wire sizes from AWG 20 to AWG 4.

Each unit is conveniently packaged in boxes containing 50 terminals, making it an excellent choice for your electrical needs.

Features and Benefits:

•RoHS compliant without exemptions.

•Requires no special tools for fitting.

•Constructed from Wemid (PA) material.

•Easy connection via ring or spade lugs.

•Client can use standard screwdriver tools.

•Equipped with touch-safe protection to IP 20.

Specifications:
