1936550000 - 4mm² Screw Mount Terminal in Grey Wemid Material (Pack of 50)

SKU: SKU: 1936550000 Download PDF

Variant:

1936550000 - 4mm² Screw Mount Terminal in Grey Wemid Material (Pack of 50)

Now $209.43

~~BEFORE $0.00~~ Now $209.43

Sold out

Web pricing policy Shipping calculated at checkout.

IN STOCK

Shipping Available

Free shipping on orders above $1000.* Only on standard purchases of cables and wires.

View full details

Product Information Resources Reviews

Product Information

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the OMNIMATE Power series WGK feed-through terminal, expertly engineered for direct screw mounting With a rated cross-section of 4 mm², this terminal is crafted from durable grey Wemid (PA) material, ensuring reliability and versatility in various applications Perfect for electrical projects that require a dependable connection, this terminal combines practicality with an efficient design.

Features and Benefits:

•Compliant with RoHS and REACH regulations.

•Suitable for a maximum operating temperature of 120 °C.

•Touch-safe protection according to DIN VDE 0470, rated IP 20.

Specifications:

Rated Voltage (IEC)	500 V
Rated Current (IEC)	32 A
Clamping Range	0.5 - 6 mm²
Tightening Torque (min)	0.6 Nm
Tightening Torque (max)	0.8 Nm
Number of Poles	1
Insulating Material	Wemid (PA)
Flammability Rating	V-0
Storage Temperature (min)	-40 °C
Storage Temperature (max)	70 °C
Operating Temperature (min)	-50 °C
Operating Temperature (max)	120 °C
Stripping Length	8 mm
Wire Connection Method	Screw connection
