2440700000 - 16mm² Feed-Through Terminal Block for Reliable Connections (Pack of 50)

Description:

Discover the WGK 16 VP TXSC BLOCK, a key component of the OMNIMATE Power series This feed-through terminal boasts a rated cross-section of 16 mm² and is expertly made from robust Wemid (PA) With impressive voltage ratings of IEC: 500 V / 76 A and UL: 600 V / 85 A, it ensures reliable performance This product is compliant with RoHS regulations, containing no SVHC above 01 wt% Engineered for secure electrical connections, it accommodates various conductor sizes ranging from 0.

5 to 25 mm², suitable for both stranded and solid wires.

Features and Benefits:

•RoHS compliant.

•Tested according to IEC 60664-1 standards.

•Configured for touch-safe protection according to DIN VDE 0470.

•Utilizes ring cable and spade lug connection methods.

•Includes a minimum and maximum tightening torque of 2 Nm and 2.3 Nm respectively.

•Can withstand storage temperatures ranging from -40 °C to 70 °C.

Specifications:
