2593170000 - IP67 Rated FIELD BUS Device with Stainless Steel Housing

2593170000 - IP67 Rated FIELD BUS Device with Stainless Steel Housing

SKU: 2593170000   Download PDF

Select a Variant:
  • 2593170000 - IP67 Rated FIELD BUS Device with Stainless Steel Housing
Qty:
Now $238.88   Web pricing policy
BEFORE   $0.00 Now $238.88 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information Resources Reviews
Product Information

Description:

This device ensures compliance with RoHS standards and is engineered to perform in various environmental settings Featuring a streamlined design, it is specifically built for the FIELD BUS FOUNDATION BUS H1 Constructed with a stainless steel screw mounting housing, it adheres to multiple safety regulations It operates efficiently within a temperature range of -30 °C to 60 °C and can handle various input power and voltage situations.

With an IP67 rating, this product is designed for resilience against tough conditions, making it a reliable choice for demanding applications.

Features and Benefits:

    •Compliant with RoHS.

    •ATEX and IECEx certifications.

    •IP67 protection rating.

    •Compatible with FIELD BUS FOUNDATION BUS H1.

    •Stainless steel screw mounting housing.

    •Measurement.

    •Monitoring.

    •Setting.

Specifications:

 Height 96 mm
 Width 24 mm
 Length 120 mm
 Diameter 28 mm
 Storage temperature -30 °C...60 °C
 Operating temperature -30 °C...60 °C
 Input power, max. P 2 W
 Input voltage, max. U 50 V
 Input current, max. I 0.8 A
 Internal capacity, max. C 0 nF
 Internal inductance, max. L 60 µH
 Dielectric strength at FG against PE ≥ 500 V
 Discharge current I max (8/20µs) wire-PE 20 kA
 Discharge current I max (8/20µs) wire-wire 20 kA
 Discharge current I n (8/20µs) wire-PE 10 kA
 Discharge current I n (8/20µs) wire-wire 10 kA
 Frequency range, max. 30 MHz
 Frequency range, min. 0 Hz
 Insertion loss 30 MHz
 Lightning test current, I imp (10/350 µs) Wire-PE 2 kA
 Lightning test current, I imp (10/350 µs) wire-wire 2 kA
 Protection level U P (typ.) < 1300 V
 Protection level, U P wire - PE 864 V
 Protection level, U P wire - wire 44 V
 Rated voltage (DC) 24 V
 Rated voltage (DC), max. 33 V
 Response time / fallback time < 1 ns
 Cross-section 1 mm²
 Wire connection method Cable length: 250 mm (min.)
