8924440000 - Surge Protection Module for 12VDC, -40 to 70 °C Temperature Range

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

The VSPC 2CL 12VDC offers reliable surge protection tailored for instrumentation and control systems, operating seamlessly without any alert or indicator This device accommodates input voltages up to 15 V and meets RoHS compliance standards With an impressive operating temperature range from -40 °C to 70 °C, it can also endure storage conditions from -40 °C to 80 °C Known for its low failure rate and high surge current capacity, this product effectively mitigates voltage surges in signal wires and ground connections, making it an ideal choice for your needs.

Features and Benefits:

•Surge protection for instrumentation and control.

•Compact dimensions with a depth of 69 mm, height of 90 mm, and width of 17.8 mm.

•Net weight of 45 g.

•High MTBF of 2,537 years.

•High protection degree of IP20.

•Measurement and monitoring systems.

•Setting control circuits.

Specifications:
