2730680000 - Compact Surge Arrester 68mm x 72mm with Remote Contact

Description:

Experience robust surge protection with the VPU AC II US 3+1 R 277/50 surge voltage arrester, expertly crafted for low voltage applications This innovative device is equipped with a remote contact feature and is compatible with various electrical systems including TN-C-S, TN-S, TT, and IT, whether or not a neutral is present It meets stringent RoHS standards and carries important certifications, including UL File Number E354261.

Measuring a compact 68 mm in depth, 1045 mm in height, and 72 mm in width, this unit is lightweight at just 473 grams Designed to perform in extreme conditions, it operates effectively within a temperature range of -40 °C to 85 °C and a humidity spectrum of 5% to 95% With impressive specifications such as a voltage rating of 277V, a maximum continuous voltage of 350V, and a short-circuit current rating of 50 kA, this surge arrester is ideally suited for diverse power distribution applications.

Features and Benefits:

•Compliant with RoHS standards.

•Multiple color options available such as orange, black, and blue.

•Includes a green optical function display indicating operational status.

•Rated for use in various low voltage networks like TN-C-S, TN-S, TT, IT with or without neutral.

•Easy installation with screw connection type.

•Low voltage surge protection.

•Power distribution systems.

Specifications:
