2736500000 - Type II 240V Surge Arrester with 20 kA Protection

2736500000 - Type II 240V Surge Arrester with 20 kA Protection

SKU: 2736500000   Download PDF

Select a Variant:
  • 2736500000 - Type II 240V Surge Arrester with 20 kA Protection
Qty:
Now $78.00   Web pricing policy
BEFORE   $0.00 Now $78.00 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information Resources Reviews
Product Information

Description:

Introducing our advanced surge arrester tailored for surge protection within single-phase TN systems This robust device ensures enhanced safety and compliance with RoHS standards and holds UL certification (E354261) With a rated voltage capacity of 240 V, it can handle a maximum discharge current of 20 kA and boasts a short-circuit current rating of 50 kA Engineered to function optimally in temperatures ranging from -40 °C to 85 °C, this arrester is highly reliable, even in humid conditions, with a tolerance of 5% to 95% humidity.

The vibrant orange color coding helps in easy identification, and it is classified as a Type II surge protective device (SPD) This product is designed for installation at altitudes of up to 4000 m, offering an IP20 protection level Users can easily monitor its operational status with color indicators: green signifies normal operation, yellow indicates warnings, and red shows defective status Protect your electrical systems efficiently with this dependable surge arrester.

Features and Benefits:

    •Surge protection for single-phase TN systems.

    •Environmental compliance with RoHS.

    •Operational temperature range from -40 °C to 85 °C.

    •IP20 protection while installed.

    •Color-coded status indicators for functional monitoring.

    •Power distribution systems.

Specifications:

 Depth 64 mm
 Height 45 mm
 Width 18 mm
 Storage temperature -40 °C...85 °C
 Operating temperature -40 °C...85 °C
 Rated Voltage U 240 V
 VPR (N-PE) 900 V
 MCOV (L/N-PE) 300 V
 SCCR 150 kA
 I n 20 kA
 Category SPD TYPE 1
 Ambient temperature (operational), max. 85 °C
 Ambient temperature (operational), min. -40 °C
 Frequency range, max. 60 Hz
 Frequency range, min. 50 Hz
 Number of poles 1
 Protection level U p at I N (L/N-PE) ≤ 1.3 kV
 Requirements category acc. to IEC 61643-11 Type II
 Response time / fallback time ≤ 25 ns
 Temporary surge voltage (over-voltage) - TOV 337 V
 Connection data Plug-in connection
 Flammability rating V-0
 Insulation coordination acc. to EN 50178 Pollution severity 2
 Surge voltage category III
 Leakage current at U n 0.3 mA
 Discharge current I max (8/20µs) wire-PE 50 kA
 Discharge current I n (8/20µs) wire-PE 20 kA
