2637000000 - Compact Surge Protector for Single-Phase Systems, 68mm Deep

Description:

Introducing the VPU AC II 2 75/50, a dependable low voltage surge protector ideal for single-phase and TN-S systems This compact device measures 68 mm deep, 90 mm tall, and 36 mm wide, weighing in at just 229 g Built to endure challenging conditions, it operates effectively in temperatures ranging from -40 °C to 85 °C and adheres to RoHS compliance standards Designed to handle a maximum continuous voltage of 75 V, it features a variety of discharge and surge voltage ratings, guaranteeing safety across multiple electrical environments.

This surge protection device falls under the SPD TYPE 1CA category, making it a perfect choice for power distribution applications.

Features and Benefits:

•Compliant with RoHS without exemption.

•Installation housing of 2TE with an IP20 protection degree.

•Optical function display indicating operational status.

•Designed for operational altitudes up to 4000 m.

•No fuse necessary for rated currents up to 315 A.

•Low leakage current at rated voltage.

•Wide clamping range accommodating various wire sizes.

•Power distribution systems.

•Single-phase applications.

•Surge protection for electrical devices.
