2591080000 - Compact Surge Protector for Low Voltage Systems, IP20 Rated

SKU: SKU: 2591080000 Download PDF

Select a Variant:

2591080000 - Compact Surge Protector for Low Voltage Systems, IP20 Rated

SET THE QTY:

Now $260.82 Web pricing policy

~~BEFORE $0.00~~ Now $260.82 Web pricing policy

Sold out

Shipping calculated at checkout.

IN STOCK
Shipping Available

Free shipping on orders above $1000. *Wires and cables only.

View full details

Product Information Resources Reviews

Product Information

Description:

Introducing the VPU AC II 3+1 300/50, specifically crafted for low voltage systems, this device is your go-to solution for surge protection across various configurations, including TN-C-S, TN-S, TT, and both types of IT systems Compliant with UL standards and ROHS certified, it guarantees reliable performance This robust unit can function seamlessly in a maximum ambient temperature of 85 °C, with an impressive operational temperature range from -40 °C to 85 °C.

Its compact design and IP20 protection rating make installation hassle-free, while it supports a wide array of voltage ratings for versatile application.

Features and Benefits:

•RoHS compliant without exemptions.

•Operating altitude of up to 4000 m.

•Features optical function display indicating operational status.

•Provides reliable surge protection across various modes.

•Integrated design for ease of installation.

•Surge protection for power distribution systems.

•Applicable in IT power systems where earth is interconnected.

Specifications:

Dimensions	{'Depth': '68 mm', 'Height': '90 mm', 'Width': '72 mm'}
Rated Voltage U	240 V
MCOV (N-PE)	305 V
SCCR	150 kA
Number of poles	4
Discharge current I_max (8/20µs) N-PE	65 kA
Response time	≤ 25 ns
Rated data IEC / EN	{'Combined pulse U_OC': '6 kV', 'Surge voltage category': 'III'}
Temperature	{'Storage temperature': '-40 °C to 85 °C', 'Operating temperature': '-40 °C to 85 °C'}
