Belden 1226B 22 AWG 32 Pair 7x30 Stranding Multiconductor and Paired Cable

Construction:-

Conductors:

Belden wire may have different numbers of conductors that are drawn and annealed by the company and made of either stranded copper.

Insulation:

• Insulation is very important in any electrical cable since it prevents the electrocution of cable handlers. Belden cable’s insulation is made by the company, therefore offering a wide range of options, including Polyethylene, Polyvinyl Chloride (PVC), and Polypropylene insulation.  Datalene and Teflon Insulated Plenum insulation is also available.

Jacket:

• The range of Belden wire jackets is quite wide and includes the following materials: Polyvinyl Chloride, Polyethylene, Polyurethane, Teflon, Tefzel, Neoprene, EPDM, Silicone rubber, and Natural rubber.

Shield:

• Belden wire shields utilize techniques and innovations developed by the company and include the following variety: Foil shields (Beldfoil, Duofoil), Braid shields, Spiral/Serve shields, and Combination shields.

Armor:

• Belden wire armor protects the cable and is made of aluminum or interlocking steel.

Details:

• Shield: Beldfoil
• Jacket Material: PVC
• Max. Voltage Rating: 300V RMS
• Conductor Material: Tinned Copper
• Max. Operating Temperature: 60°C
• Insulation Material: Datalene Polyethylene (Foam)

Standards:

• CPR Euroclass: Eca
• CEC / C(UL) Compliance: CMG
• NEC / UL Compliance: Article 800, CMR
• Environmental Suitability: Indoor - Riser
• APAC Compliance: China RoHS II (GB/T 26572-2011)
• Indoor Flammability / Fire Resistance: UL1666 Vertical Shaft, FT4, IEC 60332-1-2
• European Directive Compliance: EU CE Mark, EU Directive 2011/65/EU (ROHS II), EU Directive 2012/19/EU (WEEE)

Specifications:

• Size (AWG): 22
• Number of Conductors: 64
• Number of Pairs: 32
• Nominal Insulation O.D. (inch): 0.060
• Nominal O.D. (inch): 0.030
• Nom. Imp. (Ω): 70
• Nominal Capacitance (pF/ft): 19.0
• Conductor Material: TC - Tinned Copper
• Part Number: 1226B
