Belden 127953A 23 AWG 4 Pair Solid Bare Copper Category 6 300V DataTuff Cable

Description:-

Four Cat 6 23 AWG Bonded-Pairs solid bare copper conductors, polypropylene insulation, FRPE spline center member, inner PVC jacket, overall Beldfoil Shield (100% coverage), industrial-grade oil- and UV-resistant PVC outer jacket, CMG CM.

Insulation:-

• Material: PO - Polyolefin

Armor:-

• Armor Type and Material: AIA - Aluminum Interlock Armor
• Armor Thickness: 0.025 in (0.64 mm)
• Diameter Over Armor: 0.595 in (15.1 mm)

Outer Shield:-

• Shield Type: Tape
• Material: Bi-Laminate (Alum+Poly)
• Coverage: 100%
• Drainwire Type: 24 AWG (7x32) TC - Tinned Copper

Inner Jacket:-

• Material: PVC - Polyvinyl Chloride
• Nom. Diameter: 0.254 in (6.45 mm)

Outer Jacket:-

• Material: PVC - Polyvinyl Chloride
• Nom. Diameter: 0.695 in (17.7 mm)
• Overall Cable Diameter (Nominal): 0.695 in (17.7 mm)
• Separator: Polyester Tape

Standards:-

• UL Voltage Rating: 300 V (CMR), 300 V (CMX)
• Operating Temperature Range: -40°C to +75°C

Applications:-

• Armored Ethernet applications, in cable trays, in cabinets with high-voltage devices, such as motor control centers, mining, outdoor, harsh environments, IIoT, factory or process automation, IP cameras and devices, data communication, etc.; exposure to rodent, crush, or cut-through force

Specifications:-

• Size (AWG): 23
• No. of Pairs: 4
• Stranding: Solid
• Data Category: Category 6
• Conductor Material: BC - Bare Copper
• Part Number: 127953A
