7789807020 - 2m LiYCY Cable with HE10 & SUB-D Connectors

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Discover the convenience of the pre-assembled PAC-UNIV-HE20-S25-2M cable, designed for optimal performance with analogue signals This 2-meter long LiYCY cable features a cross-sectional area of 025 mm², encased in durable PVC material Compliant with RoHS standards, this cable ensures environmental safety while providing reliable connectivity On one end, it includes a 20-pole HE10 connector, while the other side features a SUB-D female connector with 25 poles.

With an outer diameter of 1015 mm and a tolerance of ± 1 mm, this cable is structured for ease of use and reliability.

Features and Benefits:

•High voltage test rated at 1 KV for 1 second.

•Permissible current strength of up to 1 A.

•Rated voltage capacity of ≤ 60 V DC and ≤ 25 V AC.

•Resistance measured at ≤ 80 mΩ/m.

•Total current capacity max of 3 A.

•Suitable for use with analogue signals.

Specifications:
