2736560000 - IP67 M12 Connector, 8 Poles, 8-10mm Cable Diameter

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Discover the versatility of this M12 field attachable connector, crafted with 8 poles for reliable connectivity It adheres to RoHS standards, ensuring no presence of SVHC above 01 wt% Constructed from durable PA housing and featuring a gold-plated contact surface, this connector boasts an impressive IP67 protection rating, making it ideal for challenging environments Designed to endure over 50 plugging cycles, it supports cable diameters from 8 mm to 10 mm.

With a nominal current of 2 A and a nominal voltage of 60 V, this connector is perfect for a variety of applications.

Features and Benefits:

•Compliant with RoHS standards.

•No SVHC above 0.1 wt%.

•Gold-plated contact surface.

•M12 connection for secure interfaces.

•Protection degree IP67 for high environmental resistance.

•Designed for over 50 plugging cycles.

•Accommodates cable diameters between 8 mm and 10 mm.

Specifications:
