2050490150 - 1.5m Halogen-Free Power Cable with 4 Poles

2050490150 - 1.5m Halogen-Free Power Cable with 4 Poles

SKU: SKU: 2050490150   Download PDF

Select a Variant:
  • 2050490150 - 1.5m Halogen-Free Power Cable with 4 Poles
Qty:
Regular price Now $24.05   Web pricing policy
Regular price BEFORE   $0.00 Sale price Now $24.05 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information

Description:

Introducing the SAIL-M12BG-T-15P power cable, designed with a generous length of 15 meters for versatile connectivity This model features a straight female socket and is equipped with four poles, though it comes without a connector on one end Crafted from durable PUR material, this cable is halogen-free and is designed for reliable performance without shielding or LED indicators Perfect for various power applications.

Features and Benefits:

    •Compliant with RoHS exemption.

    •Suitable for dynamic applications with a maximum acceleration of 5 m/s².

    •Capable of withstanding up to 10 million bending cycles.

    •Minimum bending radius when moving is 7.5 times the cable diameter.

    •Rated for a nominal current of 12 A and a nominal voltage of 63 V.

    •Meets IP67 protection degree when properly installed.

    •Compatible with cable carriers.

    •Temperature ranges from -40°C to +90°C when moving and -50°C to +90°C when stationary.

Specifications:

 Cable length 1.5 m
 Core cross-section 1.5 mm²
 Outer diameter 9.6 mm ± 0.3 mm
 Housing main material PUR
 Insulation PP
 Contact surface Gold-plated
 Coding T-coded
 Connection thread M12
 Sheath material PUR
 Plugging cycles ≥ 100
 Pollution severity 3
 Accelerating speed 5 m/s
