1963940150 - 1.5m PUR 4-Pole Sensor Actuator Cable with LED Indicator

1963940150 - 1.5m PUR 4-Pole Sensor Actuator Cable with LED Indicator

SKU: SKU: 1963940150

Select a Variant:
  • 1963940150 - 1.5m PUR 4-Pole Sensor Actuator Cable with LED Indicator
Qty:
Regular price Now $11.00   Web pricing policy
Regular price BEFORE   $0.00 Sale price Now $11.00 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information

Description:

Stay connected with this versatile sensor/actuator cable, measuring 15 meters in length It comes equipped with a socket on one end and features four poles, ensuring compatibility with various systems The cable is unshielded and boasts a built-in LED indicator for easy monitoring Made from a halogen-free PUR sheath, it combines safety and functionality for reliable performance.

Features and Benefits:

    •Complies with RoHS requirements.

    •Hydrolysis and microbe resistant.

    •Separate energy and signal lines.

    •Suitable for cable carriers.

    •LED indicator for functional status.

    •Angled socket for space efficiency.

    •Nominal current rating of 4 A.

Specifications:

 Cable length 1.5 m
 Number of poles 4
 Outside diameter 4.1 mm + 0.15 mm
 Sheath material PUR
 Temperature range, moving -25...60 °C
 Temperature range, stationary -50...80 °C
 Nominal voltage 24 V
 Nominal current 4 A
 Protection degree IP65, IP66, IP67, IP68 when screwed in
 Bending radius, min., moving 10 x cable diameter
 Bending radius, min., stationary 5 x cable diameter
 Halogen No
 Resistance to oils Yes
 Resistance to spread of flame In accordance with UL1581 UL / CUL FT2
