1925300800 - 8m M12 Sensor/Actuator Cable, PVC, RoHS Compliant

1925300800 - 8m M12 Sensor/Actuator Cable, PVC, RoHS Compliant

SKU: SKU: 1925300800   Download PDF

Select a Variant:
  • 1925300800 - 8m M12 Sensor/Actuator Cable, PVC, RoHS Compliant
Qty:
Regular price Now $16.27   Web pricing policy
Regular price BEFORE   $0.00 Sale price Now $16.27 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information

Description:

Enhance your connectivity with this 8-meter sensor and actuator connecting line, featuring reliable M12 connectors on both ends Designed with a straight-pin configuration for both the socket and plug, it ensures a solid connection without shielding Crafted from halogen-free PVC, this durable line meets RoHS compliance and is exempt from applicable restrictions, making it a practical choice for various applications.

Features and Benefits:

    •PVC outer cladding and insulation.

    •Core cross-section of 0.34 mm².

    •A-coded configuration.

    •Nominal current handling of 4 A.

    •Nominal voltage of 250 V.

    •IP67, IP68 when fully mounted, and IP65, IP66 ratings for protection.

    •Gold-plated contact surfaces.

    •Configured cable length available.

Specifications:

 Cable length 8 m
 Number of poles 3
 Outside diameter 4.9 mm ± 0.2 mm
 Temperature range, moving -5...80 °C
 Temperature range, stationary -30...80 °C
 Insulation resistance 10^8 Ω
 Plugging cycles ≥ 100
 Protection degree IP67, IP68 when fully mounted, IP65, IP66
 Housing main material PUR
 Connection thread M12 / M12
 Threaded ring material Diecast zinc
