1883463000 - 30m Angled Socket Cable, 8 Poles, PUR Sheath

1883463000 - 30m Angled Socket Cable, 8 Poles, PUR Sheath

SKU: SKU: 1883463000

Variant:
  • 1883463000 - 30m Angled Socket Cable, 8 Poles, PUR Sheath
Regular price Now $74.08
Regular price BEFORE   $0.00 Sale price Now $74.08
Sold out
IN STOCK
Shipping Available
Free shipping on orders above $1000.* Only on standard purchases of cables and wires.
View full details
Product Information

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Discover the versatility of this sensor/actuator product, featuring a robust 8-pole configuration and extending over 30 meters in length It is designed as an angled socket, offering practical functionality without shielding or an LED indicator Constructed with a durable PUR sheath, this cable adheres to RoHS standards, ensuring it meets environmental regulations for safety and sustainability.

Features and Benefits:

    •Suitable for cable carriers.

    •Not configurable in length.

    •Resistance to welding beads: No.

    •Plugging cycles count: ≥ 100.

Specifications:

 Cable length 30 m
 Core cross-section 0.25 mm²
 Number of poles 8
 Outer diameter 5.9 mm ± 0.2 mm
 Temperature range, moving -25...80 °C
 Temperature range, stationary -40...80 °C
 Protection degree IP67 when screwed in, IP65, IP66
 Nominal voltage 30 V
 Rated current 2 A (8-pole) / 1.5 A (12-pole)
 Insulation resistance 10^8 Ω
 Connection thread M12
