1465910500 - 5m M8 Sensor/Actuator Cable, 4 Poles, PVC Material

1465910500 - 5m M8 Sensor/Actuator Cable, 4 Poles, PVC Material

SKU: SKU: 1465910500

Select a Variant:
  • 1465910500 - 5m M8 Sensor/Actuator Cable, 4 Poles, PVC Material
Qty:
Regular price Now $9.75   Web pricing policy
Regular price BEFORE   $0.00 Sale price Now $9.75 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information

Description:

Introducing our versatile sensor/actuator line, equipped with an M8 connector on one end and featuring a four-pole configuration This cable stretches to a generous 5 meters in length and is constructed from durable PVC material Please note, it does not include shielding for the connection, nor does it come with an LED indicator Perfect for your connectivity needs, this product is designed for reliable performance in various applications.

Features and Benefits:

    •Halogen-free product.

    •Conforms to RoHS standards.

    •Designed with an angled socket.

    •Outer sheath made from PVC.

    •Pressure resistance classified under IP65, IP66, IP67, and IP68 when properly secured.

    •Gold-plated contact surfaces for better conductivity.

    •Suitable for installation within a temperature range of -30°C to +80°C.

Specifications:

 Cable length 5 m
 Core cross-section 0.25 mm²
 Number of poles 4
 Outer diameter 4.8 mm ± 0.2 mm
 Nominal current 4 A
 Nominal voltage 30 V
 Insulation resistance 10^8 Ω
 Protection degree IP65, IP66, IP67, IP68
 Temperature range of housing -25…+85 °C
 Threaded ring material POM
 Tightening torque M8: 0.5 - 0.6 Nm
