Description:
Enhance your connectivity with this 3-meter bus line cable, designed with two poles at one end without any connector Crafted from durable shielded PUR sheath material, this cable functions effectively in a temperature range of -20 to 60 °C during movement and withstands -40 to 70 °C when stationary Measuring an outer diameter of 78 mm, it reflects sturdy construction and meets RoHS and REACH compliance standards, ensuring safety and quality.
Features and Benefits:
•Shielded design for enhanced performance.
•High durability with a resistance rating for bending cycles totaling up to 2 million.
•IP67 protection degree indicating protection against dust and water.
•Nickel-plated brass threaded ring for better connectivity.
•Color coding for easier identification.
Specifications:
| Acceleration | 5 m/s² |
| Bending radius, min., moving | 12 x cable diameter |
| Bending radius, min., stationary | 7.5 x cable diameter |
| Cable length | 3 m |
| Core cross-section AWG | AWG 24 |
| Insulation | TPE |
| Number of poles | 2 |
| Outer cladding in accordance with UL AWM style | 20236 (80 °C / 30 V) |
| Resistance to welding beads | No |
| Sheath material | PUR |
| Speed | 3 m/s |
| Suitable for cable carriers | Yes |
| Nominal current | 4 A |
| Nominal voltage | 250 V |
| Plugging cycles | ≥ 100 |
| Protection degree | IP67 |
| Temperature range of housing | -25…+80 °C |
