Product Information

Description:

Introducing a robust Dragline cable specifically engineered for PROFINET applications This cable features durable M12 D-code connectors with an IP67 protection rating, ensuring resistance against dust and moisture It meets the rigorous standards of both Cat5 and Cat5e, following ISO/IEC 11801 and TIA T568-B guidelines With a length of 02 mm and various certifications backing its quality, this cable is also compliant with RoHS directives, verified by certificate number E316369.

Features and Benefits:

•Forbidden for a broad range of industrial applications due to IP67 protection.

•Designed for high durability under challenging environmental conditions.

•Special cable construction with extensive shielding for superior performance.

•Excellent abrasion and chemical resistance.

Specifications:

Length	0.2 mm
Storage temperature	-50 °C...70 °C
Installation temperature	-20 °C...60 °C
Timber layer resistance	3 %
Characteristic impedance	100 ± 15 Ω at 1–100 MHz
Operating voltage	600 V
Resistance differential	3 %
Delay skew	40 ns/100m
Speed	180 m/min
Bending cycles	3 Mio
Test voltage	2000 V eff, 50 Hz, 1 min
Cable structure	Star-quad
Sheathing colour	green (RAL 6018)
Sheath diameter, max	6.7 mm
Sheath diameter, min	6.3 mm
Wire core insulation thickness	0.38 mm
Wire material	Stranded tin-plated copper wire
Shielding	SF/UTP
