1021760300 - 3m M12 Sensor/Actuator Cable with 3 Poles, No Connector

1021760300 - 3m M12 Sensor/Actuator Cable with 3 Poles, No Connector

SKU: SKU: 1021760300

Select a Variant:
  • 1021760300 - 3m M12 Sensor/Actuator Cable with 3 Poles, No Connector
Qty:
Regular price Now $8.97   Web pricing policy
Regular price BEFORE   $0.00 Sale price Now $8.97 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information

Description:

Introducing the SAIL-M12W-3-30T sensor and actuator line cable, designed for versatile connectivity With a length of 3 meters and featuring a 3-pole M12 connector at one end, this cable is perfect for various applications It is crafted from a halogen-free PUR sheath, ensuring safety and compliance, while being straightforward in design with no shielding or LED indicators Ideal for those seeking reliable and efficient connection solutions.

Features and Benefits:

    •Compliant with RoHS regulations.

    •Meets compliance for various environmental standards.

    •Suitable for various industrial applications.

    •Non-shielded design for enhanced flexibility.

    •Configured for a specific number of bending cycles.

Specifications:

 Cable Length 3 m
 Number of Poles 3
 Core Cross-section 0.34 mm²
 Outer Diameter 4.9 mm ± 0.2 mm
 Temperature range, moving -30...105 °C
 Temperature range, stationary -40...105 °C
 Resistance to welding beads Yes
 Speed 200 m/s
 Nominal Current 4 A
 Nominal Voltage 250 V
 Protection degree IP67, IP68 when screwed in
 Insulation Resistance 10^8 Ω
 Plugging Cycles ≥ 100
 Coding A-coded
 Connection Thread M12
 Contact Surface Gold-plated
 Housing Main Material PUR
