2790430000 - 5mm PCB Female Connector, 6 Poles, 400V, 26.8A (Pack of 60)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing a reliable PCB plug-in female connector, designed with a 5 mm pitch and accommodating 6 poles This connector boasts a robust voltage rating of 400 V, along with the capacity to manage currents up to 268 A It supports wire sizes ranging from 05 to 4 mm² Compliant with RoHS standards and rigorously tested under IEC guidelines, this connector guarantees safety and dependability Additionally, its construction meets DIN standards for touch-safe protection, ensuring secure operation in various applications.

Features and Benefits:

•Field connection type.

•Snap-in wire connection with lever.

•Environmentally compliant with RoHS.

•Touch-safe protection according to DIN VDE.

•IP 20 protection degree.

•Lightweight at 15.258 g.

Specifications:
